ULTRA NT SCIF Barrier SOLID | 106.8 dB Shielding | 100 MHz–10 GHz.

ULTRA NT SCIF Barrier SOLID | 106.8 dB Shielding | 100 MHz–10 GHz.

by National Building Supplies, LLC
Save 40% Save 40%
$265.00
$265.00 - $265.00
$265.00
$160.00
$160.00 - $160.00
$160.00

Exclusively available through National Building Supplies, LLC, and our authorized website ULTRANTSCIFBarrier.com, and is not available for purchase through rFoil, Covertech, Eco Foil, or through any unauthorized supply houses, online resellers, including Amazon.

ULTRA NT SCIF Barrier SOLID | 106.8 dB Shielding | 100 MHz–10 GHz performance has been tested across frequencies from 100 MHz to 10 GHz, in accordance with IEEE-299 testing guidelines, and is fully compliant with the Sensitive Compartmented Information Facilities (SCIF) application guidelines. The barrier provides effective RF attenuation against a wide range of RF frequencies, and is Buy American Act compliant—ideal for military and government applications.

Why Choose ULTRA NT SCIF Barrier – SOLID?

  • Exceptional Shielding: 106.8 dB Shielding | 100 MHz – 10 GHz and 91.7 dB Minimum Shielding Tested Between 30 MHz – 18 GHz
  • SCIF Compliant: Meets all IEEE-299 and federal SCIF standards

  • American-Made: Buy American Act compliant—ideal for military and government applications

Tested. Trusted. Certified.
Performance validated by MET Laboratories using NIST-traceable equipment. Full test results are available by calling (800) 753-9090

Product Documents

  • Product Submittal: CLICK HERE
  • Technical Data Sheet: CLICK HERE
  • Installation Instructions: Click Here
  • Tapes and Accessories: Click Here

To Get Your Copy of the Comprehensive Product Testing Report, Call (800) 753-9090

Additional Product Specification and Details

1.      Shielding Effectiveness tested between the frequencies of 100 MHz to 10 GHz equals a minimum shielding effectiveness of 106.8 dB, following IEEE-299-2006 testing standards.

2.      Shielding Effectiveness tested between the frequencies of 30 MHz to 18 GHz equals a minimum shielding effectiveness of 91.7 dB following IEEE-299-2006 testing standards.

3.      Roll Size: 48 inches wide x 125 feet long (500 square feet per roll)

4.      Manufactured in the United States and is Buy American Act compliant

5.      Material: Two-sided reflective aluminum foil with polyethylene woven reinforcement with a combined 6.52 mil thickness.

6.      Emissivity: ASTM C1371-04A = 0.03

7.      Reflectivity: Reflects 97% of radiant heat

8.      Corrosiveness: Passes ASTM D3310-00

9.      Fire Rating: Class 1, Class A (ASTM E84-10)

10. Flame Spread and Smoke Development: Flame spread = 0, Smoke development

11. Bleeding and Delamination: No bleeding or delamination (ASTM C1224-03)

12. Pliability: No cracking (ASTM C1224-03)

13. Water Vapor Permeability: 0.0027 Perm rating (ASTM E96-05)

14. Resistance to Fungi: No growth (ASTM C1338-08)

15. Tensile Strength and Tear Resistance (Length): 101.47 pounds of force

16. Tensile Strength and Tear Resistance (Width): 86.22 pounds of force

17. Product thickness equals 6.52 mils
